HOME DESIGN SERVICE OTHER PRODUCTS CONTACT Avanti Digital Quartzdyne Tester & PC-Interface. Quartz Transducers are widely used in the oil industry for measuring downhole pressure and temperature with very high accuracy. The latest generation of Quartzdyne Transducers (Quartzdyne DM, DS and DX series) include high resolution frequency counters and provide a two-wire serial I2C interface instead of the traditional frequency outputs. Due to their digital interface they are called digital pressure transducers. These new digital transducers have many benefits over their conventional counterparts. However, their correct operation cannot be checked as easily. While a frequency output transducer requires only a frequency counter for a quick check, there is no such simple test for an I2C transducer. The Avanti AVA-03 I2C Transducer Tester & PC Interface overcomes this problem. It communicates with up to 4 I2C transducers simultaneously and displays pressure and temperature readings on a backlit LCD. Readings can be displayed either as raw counts, as equivalent frequencies in Hz or as engineering values in psi/bar and degC/degF (user selectable). Additional information such as transducer serial number and calibration date are also shown on the LCD. The AVA-03 Digital Transducer Tester contains an RS232 interface for accessing readings and calibration coefficents from a PC. This is particularly useful if a transducer requires re-calibration. The RS232 interface can also be set up to output data at a regular rate, which can be logged to file using standard terminal emulation software (e.g. Hyperterminal). The resulting ascii file can be imported into standard spreadsheet software (e.g. Excel) for further analysis. The AVA-03 Digital Transducer Interface/Tester is a perfect alternative to a Quartzdyne Q-Link interface, providing a simplified command set and extra functionality through the built-in display and battery operation. Model-No: AVA-03 Price: £895.- + VAT. Please contact Avanti for price in USD or EUR. TOP OF PAGE USER MANUAL (PDF) WWW.QUARTZDYNE.COM
